| General |
|
| UPS Topology |
Line-interactive |
| Energy Saving Technology |
GreenPower UPS™ Bypass Technology |
| Input |
|
| Generator Compatibility |
Yes |
| Nominal Input Voltage (Vac) |
230 ± 10% |
| Input Voltage Range (Vac) |
167 ~ 295 |
| Input Frequency (Hz) |
50 ± 5, 60 ± 5 |
| Input Frequency Detection |
Auto-sensing |
| Rated Input Current (A) |
2.83 |
| Input Connector Type |
Schuko |
| Output |
|
| Capacity (VA) |
650 |
| Capacity (Watts) |
360 |
| On Battery Waveform |
Simulated Sine Wave |
| On Battery Voltage(s) (Vac) |
230 ± 10% |
| On Battery Frequency (Hz) |
50 ± 1%, 60 ± 1% |
| Automatic Voltage Regulation (AVR) |
Single Boost, Single Buck |
| Overload Protection |
Internal Current Limiting |
| Outlet(s) - Total |
3 |
| Outlet Type |
Schuko x 3 or FR x 3 |
| Outlet(s) - Battery & Surge Protected |
3 |
| Typical Transfer Time (ms) |
4 |
| Battery |
|
| Runtime at 60W (min) |
30 |
| Runtime at 90W (min) |
18 |
| Typical Recharge Time (Hours) |
8 |
| User-replaceable |
No |
| Battery Type |
Sealed Lead-acid |
| Surge Protection & Filtering |
|
| Surge Suppression (Joules) |
150 |
| EMI/RFI Filtration |
Yes |
| Management & Communications |
|
| LED Indicators |
Power On, Line Mode, Battery Mode, Low Battery |
| Audible Alarms |
Battery Mode, Low Battery, Overload, UPS Fault |
| Physical |
|
| Form Factor |
Desktop |
| Physical Size - UPS Module |
|
| Dimensions (WxHxD) (mm.) |
158 x 91.5 x 240 |
| Weight (kg.) |
3,8 |
| Environmental |
|
| Operating Temperature (°C) |
0 ~ 40 |
| Operating Relative Humidity |
0 ~ 90 |
| (Non-condensing) (%) |
44,3 |
| Online Thermal Dissipation (BTU/hr) |
|
| Certifications |
|
| Certifications* |
CE |
| RoHS |
Yes |
